LMW-AD - Linear Multistream Wall Diffuser



LMW-AD - Linear Multistream Wall Diffuser

High induction linear wall slot diffuser with alternating multi-stream mini-jets discharged by nozzle barrels. Nozzle barrel discharge direction is individually adjustable through 90° to alter air pattern vertically. Suitable for installation in the side of a wall or bulkhead.

LMW-AD

Volume flow rate range:

10 – 133 L/s/m (36 – 479 m³/h/m)

Nominal length:

  • 1200 mm
  • Bespoke lengths and joining strips available on request
  • Available with or without side/end flanges

Element width:

  • Flangeless: 1 slot = 31 mm; 2-slot = 65 mm
  • Flanged: 1 slot = 48 mm; 2-slot = 76 mm

Discharge height:

2.5 – 4 m

  • 1 - 2 slot configurations
  • Air pattern vertically adjustable
  • High induction alternating mini-jet discharge
  • Barrel nozzles individually adjustable through 90°
  • Barrel nozzles of plastic, black
  • Side and end profiles of aluminium, natural anodised or powder coated
  • Flanged or flangeless side and end profiles
  • Installation flush with wall or bulkhead

Technical Data
