CNW-AD Circular Nozzle



CNW-AD Circular Nozzle

The SMARTEMP Circular Nozzle (CNW-AD) is an eyeball nozzle with adjustable discharge direction suitable for long horizontal throw applications when discharging a jet, or medium horizontal throw applications when discharging a swirl pattern. Suitable for installation in walls or bulkheads.

CNW-AD

Volume flow rate range:

70 – 4000 L/s (250 – 14,400 m³/h)


Nominal Neck Sizes:

  • DN100 - jet discharge; manual adjustment
  • DN125 - jet discharge; manual adjustment
  • DN160 - jet discharge; manual adjustment
  • DN200 - jet discharge; manual adjustment
  • DN250 - jet or swirl discharge; manual adjustment
  • DN315 - jet or swirl discharge; manual, thermal or electric adjustment
  • DN400 - jet or swirl discharge; manual, thermal or electric adjustment
  • DN500 - jet or swirl discharge; manual, thermal or electric adjustment
  • DN630 - jet discharge; manual, thermal or electric adjustment

Throw:

3 - 60 m

Discharge Height:

3 - 10 m

  • Round eyeball nozzle
  • Jet discharge for long throw - DN100 to DN500
  • Optional swirl discharge for reduced throw - DN250 to DN500
  • Manual adjustment - DN100 to DN630
  • Optional actuator adjustment (electric, or thermal with adjustable bias) - DN315 to DN630
  • 60° arc of discharge direction adjustment (ie ±30° from central axis)
  • Connection to pressure plenum, or to flexible or spiral duct via rear-side entry spigot
  • Powder coated aluminium

Technical Data

CNW-AD Circular Nozzle

CNW-AD Circular Nozzle

CNW-AD Circular Nozzle

CNW-AD Circular Nozzle
