ISF-AD Inclined Floor Swirl Diffuser



SSC-AD - Slotted Swirl Diffuser

The SMARTEMP Slotted Swirl Diffuser, type SSC-AD, is a high induction radial slot ceiling swirl diffuser with manually adjustable discharge direction and pattern.

Supply air is discharged in a highly inductive swirling motion that strongly dilutes the supply air stream as it disperses into the space. Supply air direction is manually adjustable from a horizontal radial to downward vertical discharge. The air pattern may be manually set to 4-way, 3-way or 2-way blow.

ISF-AD

Volume flow rate range:

10 – 55 L/s (36 – 198 m³/h)


Nominal Size:

  • DN200

Discharge height:

0 m

  • User-adjustable airflow rate.
  • User-adjustable inclined air stream direction.
  • User-adjustable air motion (gentle inclined breeze to draught-free vertical plume).
  • User-adjustability by rotation of the diffuser face.
  • VAV damper user-adjustable or electrically motorised.
  • Constant throw to head height of occupants throughout VAV damper range prevents cold feet / warm head at low airflow rates.
  • Low profile basket and damper assembly, suitable for shallow floor plenum.

Unique features include:

  • 20 radially off-set swirl vanes increase induction.
  • Swirl vanes with helical twist reduce pressure drop and increase capacity.
  • Low pressure drop reduces fan energy.
  • High capacity airflow reduces architectural impact.
  • Flush face enhances aesthetics.

Technical Data

ISF-AD Inclined Floor Swirl Diffuser

ISF-AD Inclined Floor Swirl Diffuser

ISF-AD Inclined Floor Swirl Diffuser

ISF-AD Inclined Floor Swirl Diffuser

ISF-AD Inclined Floor Swirl Diffuser
