LMC-AD - Linear Multistream Ceiling Diffuser

The SMARTEMP Linear Multistream Ceiling Diffuser, type LMC-AD, is a high induction linear slot diffuser. A multitude of barrel nozzles produce alternating mini-jet discharge. The discharge direction of each barrel nozzle is individually adjustable, providing accurate air pattern adjustment. The diffuser is available with 1-way (adjustable through 90° for horizontal through diagonal to vertical discharge) or 2-way discharge patterns (each direction adjustable through 90° for horizontal through diagonal to vertical discharge).

LMC-AD

Volume flow rate range:

6 – 228 L/s/m (22 – 821 m³/h/m)

Nominal Length:

  • 1200 mm neck
  • 1195 mm face
  • Other lengths and joining strips available on request
  • Flanged or flangeless side and end profiles

Element width:

  • Flangeless: n x 28 + 3 mm, where n = number of rows (1 to 6 rows)
  • Flanged: n x 28 + 20 mm, where n = number of rows (1 to 6 rows)

 Discharge height:

2.4 – 4.5 m

  • 1 - 8 slot configurations
  • 1 or 2 way discharge patterns
  • Adjustable horizontal, diagonal or vertical discharge direction
  • High induction alternating mini-jet discharge
  • Barrel nozzles individually adjustable through 90°
  • Barrel nozzles of plastic, black
  • Side and end profiles of aluminium, natural anodised or powder coated
  • Flanged or flangeless side and end profiles
  • Installation flush with ceiling or free hanging
