CP-AD - Cylindrical Plug-flow Diffuser

Adjustable pattern plug-flow air supply from up to 3 m discharge height in industrial applications for spot cooling/heating and to purge contaminants from work areas.

LMC-AD

Volume flow rate range:

  • ≤ 2 800 L/s (10 000 m³/h)
  •

Nominal Sizes:

  • DN250
  • DN450
  • DN560
  • DN630

Primary penetration radius:

  • ≤ 14 m

 Maximum supply air penetration radius:

  • ≤ 20 m

  • Low-turbulence plug-flow purges contaminants for enhanced IAQ.
  • Well suited for spot cooling and heating
  • Placement at approx. 3 m height or on the floor, free standing in room or in front of a pillar or wall
  • Radial discharge pattern
  • Stepless air pattern direction adjustment from slightly inclined to vertical downflow
  • Adjustment by hand, electric actuator or self-acting thermal wax-bulb in the supply air stream
