In-line Pump
Single-stage, low-pressure centrifugal pump, in-line design.
Pumping of heating water (acc. to VDI 2035), cold water and water/glycol mixtures without abrasive substances in heating, cold water and cooling systems.
VeroLine IPL (Low Flow)
Technical Data:
- Permissible temperature range:
- -20 °C to +120 °C
- Mains connection:
- 3~400 V, 50 Hz (others on request)
- Protection class IP 55
- Nominal diameter Rp 1 to DN 100
- Max. operating pressure 10 bar (special version: 16 bar)
- High standard of corrosion protection thanks to cataphoretic coating
- Standard condensate drainage holes in the motor housings and lanterns
- Series design: motor with one-piece shaft
- Version N: Standard motor V1 with stainless steel plug shaft
- Bidirectional, force-flushed mechanical seal
Construction:
Glanded pump in in-line design with screwed connection or flange connection.
Materials:
- Pump housing and lantern: EN-GJL-250
- Impeller: PPO fibreglass-reinforced EN-GJL-200 (depending on pump type)
- Shaft: 1.4021
- Mechanical seal: AQEGG; other mechanical seals on request
Application:
Pumping of heating water (acc. to VDI 2035), cold water and water/glycol mixtures without abrasive substances in heating, cold water and cooling systems.
